7x Kit Replacement PCB (Simube Hub)

A replacement PCB for the 7x conversion kit.

This version has two extra resistors added manually to enable the Simube Hub to work as well as genuine Fanatec wheels.

You can add these yourself to the standard 7x PCB as per the diagram.  Add 2 x 10k resistors between the I2C data pins and the 3.3v as shown.

This makes everything work for me, but as I don't officially support the Simube hub this is a work around and although it should work I offer no guarantee.

Just to explain why this is needed....

Fanatec have these resistors in both their wheels and the wheelbases - but Simube did not include them in their hub.  So because we are not on a Fanatec wheelbase these are needed on either the hub or the conversion kit.  Because Fanatec wheels already have them we did not include them on the kit, but neither did Simube.

When I next revise the kit PCB i will include these as they will not cause any issues on Fanatec wheels so there is no downside to adding them.
